A_meltpump Melt Pump


Process Material/Polymers:
PS, PET, PC, PA, PMMA + HDPE + LDPE + LLDPE + PP + Poly Sulphure + PEEK.

Technical features:

  • Rajhans Melt Pumps are compact and give extraordinary result when installed with extrusion process plant.
  • The melt pump can be operated with 350 bar and 350ºC temperature with inlet pressure 125 bar and outlet pressure 350 bar.
  • Generally all the Melt Pump material is made from heat resistant carbon steel, tool steel and alloy steel.
  • Comes with high quality cartridge heaters.

We will be pleased to offer you special materials and differing designs upon request.


The operating parameters:

  • Viscosity – up to 30,000 PAS
  • Temperature – up to 350ºC
  • Inlet pressure – up to Max.120 Bar
  • Differential pressure – up to 250 Bar
  • Outlet pressure – up to Max.350 Bar
